Force Gauge Sauter FC

£360.00 - £360.00
Choose model
Kern Standard
Mains adapter Rechargeable battery pack RS 232 data interface USB data interface Peak hold function Scan mode Push and Pull Internal memory Measuring with tolerance range (function to set limits) ZERO Dimensional units
Kern Options
Certificate_DAkkS_4_days Certificate_ISO_4_days PC software
Short Description
The Sauter FC force gauge offers real-time and peak hold modes for reading constant loads or fluctuations – so-called peaks. Limit values can be set, providing both audible and visual signals when they are reached. The display features a bar that follows the load, allowing you to track changes. Wi .... Read the full description
FC 500
FC 500
FC 500
See specifications
Special Price £367.20 £306.00 £432.00 £360.00
500 N Maximum capacity
0,1 N readout
0,3% Measuring accuracy
Case, Standard set of attachments
150%
Yes
Yes
No
Yes
No
20
20
Internal loadcells
N, lbf, ozf, kgf
Ja - 500 værdier
Yes
Charger (Incl.), Rechargeable battery (Incl.)
RS-232 (Included), USB (Included)
0,45 kg
-10 °C / 40 °C
Calibration Certificate / Verification
£143.65
£261.80
£143.65
Special Price £367.20 £306.00 £432.00 £360.00
FC 100
FC 100
FC 100
See specifications
Special Price £367.20 £306.00 £432.00 £360.00
100 N Maximum capacity
0,1 N readout
0,3% Measuring accuracy
Case, Standard set of attachments
150%
Yes
Yes
No
Yes
No
20
20
Internal loadcells
N, lbf, ozf, kgf
Ja - 500 værdier
Yes
Charger (Incl.), Rechargeable battery (Incl.)
RS-232 (Included), USB (Included)
0,95 kg
-10 °C / 40 °C
Calibration Certificate / Verification
£143.65
£261.80
£143.65
Special Price £367.20 £306.00 £432.00 £360.00
FC 1K
FC 1K
FC 1K
See specifications
Special Price £367.20 £306.00 £432.00 £360.00
1 kN Maximum capacity
1 N readout
0,3% Measuring accuracy
Case, Standard set of attachments
150%
Yes
Yes
No
Yes
No
20
20
Internal loadcells
N, lbf, ozf, kgf
Ja - 500 værdier
Yes
Charger (Incl.), Rechargeable battery (Incl.)
RS-232 (Included), USB (Included)
0,95 kg
-10 °C / 40 °C
Calibration Certificate / Verification
£173.40
£173.40
£324.70
Special Price £367.20 £306.00 £432.00 £360.00
FC 50
FC 50
FC 50
See specifications
Special Price £367.20 £306.00 £432.00 £360.00
50 N Maximum capacity
0,01 N readout
0,3% Measuring accuracy
Case, Standard set of attachments
150%
Yes
Yes
No
Yes
No
20
20
Internal loadcells
N, lbf, ozf, kgf
Ja - 500 værdier
Yes
Charger (Incl.), Rechargeable battery (Incl.)
RS-232 (Included), USB (Included)
0,95 kg
-10 °C / 40 °C
Calibration Certificate / Verification
£143.65
£261.80
£143.65
Special Price £367.20 £306.00 £432.00 £360.00
FC 10
FC 10
FC 10
See specifications
Special Price £367.20 £306.00 £432.00 £360.00
10 N Maximum capacity
0,01 N readout
0,3% Measuring accuracy
Case, Standard set of attachments
150%
Yes
Yes
No
Yes
No
20
20
Internal loadcells
N, lbf, ozf, kgf
Ja - 500 værdier
Yes
Charger (Incl.), Rechargeable battery (Incl.)
RS-232 (Included), USB (Included)
0,50 kg
-10 °C / 40 °C
Calibration Certificate / Verification
£143.65
£261.80
£143.65
Special Price £367.20 £306.00 £432.00 £360.00
pencil-alt

Description

SAUTER FC Force Gauge offers real-time and peak hold modes for reading constant loads or fluctuations – so-called peaks. Limit values can be set, giving both audible and visual signals when these are reached. The display shows a bar that follows the load, allowing you to track the force development. With its high memory capacity, the gauge can store up to 500 readings.

Connection:
Delivered as standard with RS232 and USB interfaces. Can be mounted on all SAUTER force gauge stands.

Power Supply:
The force gauge comes standard with a power supply and rechargeable battery.

Functions:
- Peak hold function
- Track mode for continuous measurement
- Measurement of both compression and tension
- Adjustable upper and lower limit values

Features:
- Supports multiple units of measurement (N, lbf, kg, ozf)
- Standard accessory set included
- Memory for 500 values

Notice:
All products come with an English manual If you have any questions about the use of the scale, you are welcome to contact us.
clipboard-list

General

Manufacturer Sauter
SKU sauter-fc
Type Force gauge
truck

Delivery

Estimated delivery time 3-5 business days
cog

Technical Specifications

Battery Included Yes
Battery life (hours) 20
Internal/External Loadcells Internal loadcells
Overload Protection 150%
Peak function Yes
nan Yes
Limit function Yes
Data Output RS-232 (Included), USB (Included)
Power Supply Charger (Incl.), Rechargeable battery (Incl.)
