Wall Thickness Gauge Sauter TD-US

£421.00 - £421.00
Choose model
Kern Standard
Battery operation RS 232 data interface Calibration block
Kern Options
Certificate_ISO_4_days PC software
Short Description
The SAUTER TD-US thickness gauge is delivered complete and ready to use – including measuring sensor, batteries, calibration plate, and ultrasound gel – all packed in a sturdy and practical case. The calibration plate is integrated into the gauge, so it is always readily available. The gauge use .... Read the full description
TD 225-0.1US
TD 225-0.1US
TD 225-0.1US
See specifications
Special Price £429.42 £357.85 £505.20 £421.00
1.2 - 225 mm Range
0.1 mm readout
0.5% Measuring accuracy
0.9 m
Case, Batteries, External measurement sensor, Ultrasound contact gel
No
No
No
8 mm
5 MHz
1000-9999 m/s
No
1.5 V AAA
Yes
4
0,20 kg
0 °C / 50 °C
Calibration Certificate / Verification
£128.35
Special Price £429.42 £357.85 £505.20 £421.00
pencil-alt

Description

SAUTER TD-US Ultrasonic Thickness Gauge is delivered complete and ready to use – including measuring sensor, batteries, calibration plate, and ultrasonic gel – all packed in a sturdy and practical case. The calibration plate is integrated into the gauge, so it is always at hand. The gauge uses ultrasound to measure material thickness. Sound velocities for various materials are pre-set, making the gauge easy to use on multiple material types. Additionally, it is possible to set the sound velocity for other materials. The TD-US is equipped with an RS-232 port, allowing data transfer.

Pre-set materials:
Steel, cast iron, aluminium, copper, brass, zinc, quartz glass, polyethylene, PVC, grey cast iron, nodular cast iron.

Connection:
Comes standard with an RS-232 interface.

Power supply:
The gauge comes standard with 4 x AAA batteries.

Features:
- Supplied in a robust case
- Calibration plate integrated into the gauge

Notice:
All products come with an English manual If you have any questions about the use of the scale, you are welcome to contact us.
clipboard-list

General

Manufacturer Sauter
SKU sauter-td-us
Type Thickness gauge
truck

Delivery

Estimated delivery time 3-5 business days
cog

Technical Specifications

Temperature 0 °C / 50 °C
Cable length 0,9 m
Number of batteries 4
Battery type 1.5 V AAA
Measuring accuracy 0,5%
nan No
Echo-echo function No
Memory No
Limit function No
Included in the delivery Case, Batteries, External measurement sensor, Ultrasound contact gel
